Mass
Approx. 1895g (Body only)
Approx. 4lb 3 oz (Body only)
Approx. 2270 g (with lens hood, eyecup, NP-F770 battery)
Approx. 5 lb (with lens hood, eyecup, NP-F770 battery)
Approx. 4lb 3 oz (Body only)
Approx. 2270 g (with lens hood, eyecup, NP-F770 battery)
Approx. 5 lb (with lens hood, eyecup, NP-F770 battery)
Dimensions (W x H x D) *1
171.3 × 187.8 × 371.3 mm (With the accessories (lens hood, large eyecup), excluding the grip belt and including the projecting parts)
6 3/4 x 7 3/8 x 14 5/8 inches (With the accessories (lens hood, large eyecup), excluding the grip belt and including the projecting parts)
6 3/4 x 7 3/8 x 14 5/8 inches (With the accessories (lens hood, large eyecup), excluding the grip belt and including the projecting parts)
Power Requirements
DC In: 8.4V, Battery: 7.2 V
Power Consumption
Approx. 6.3 W (while recording with viewfinder and XAVC HD 1080/60i 50 Mbps)
Approx. 6.6 W (while recording with LCD and XAVC HD 1080/60i 50 Mbps)
Approx. 6.6 W (while recording with LCD and XAVC HD 1080/60i 50 Mbps)
Operating Temperature
0°C to 40°C
32°F to 104°F
32°F to 104°F
Storage Temperature
-20°C to +60°C
-4°F to +140°F
-4°F to +140°F
Battery Operating Time
Approx. 260 min. with NP-F770 battery (while recording with LCD, XAVC 1080/60i, 50 Mbps)
Approx. 400 min. with NP-F970 battery (while recording with LCD, XAVC 1080/60i, 50 Mbps)
Approx. 400 min. with NP-F970 battery (while recording with LCD, XAVC 1080/60i, 50 Mbps)
Recording Format (Video)
XAVC QFHD: MPEG-4 AVC/H.264 4:2:0 Long profile
XAVC HD : MPEG-4 AVC/H.264 4:2:2 Long profile
XAVC Proxy: MPEG-4 AVC/H.264 4:2:0 Long profile
MPEG HD422: MPEG-2 422P@HL 4:2:2 Long profile
MPEG HD420: MPEG-2 MP@HL 4:2:0 Long profile
MPEG HD Proxy: MPEG-4 AVC/H.264 4:2:0 Long profile
AVCHD : MPEG-4 AVC/H.264 AVCHD 2.0 format compatible
XAVC HD : MPEG-4 AVC/H.264 4:2:2 Long profile
XAVC Proxy: MPEG-4 AVC/H.264 4:2:0 Long profile
MPEG HD422: MPEG-2 422P@HL 4:2:2 Long profile
MPEG HD420: MPEG-2 MP@HL 4:2:0 Long profile
MPEG HD Proxy: MPEG-4 AVC/H.264 4:2:0 Long profile
AVCHD : MPEG-4 AVC/H.264 AVCHD 2.0 format compatible
Recording Format (Audio)
XAVC QFHD : Linear PCM 2ch, 24bit, 48kHz
XAVC HD : Linear PCM 2ch, 24bit, 48kHz
XAVC Proxy : AAC-LC 2ch, 16bit, 48kHz
MPEG HD422 : Linear PCM 2ch, 24bit, 48kHz
MPEG HD420 : Linear PCM 2ch, 16bit, 48kHz
MPEG HD Proxy : AAC-LC 2ch, 16bit, 48kHz
AVCHD : Linear PCM 2ch, 16bit, 48kHz Dolby Digital 2ch, 16bit, 48kHz
XAVC HD : Linear PCM 2ch, 24bit, 48kHz
XAVC Proxy : AAC-LC 2ch, 16bit, 48kHz
MPEG HD422 : Linear PCM 2ch, 24bit, 48kHz
MPEG HD420 : Linear PCM 2ch, 16bit, 48kHz
MPEG HD Proxy : AAC-LC 2ch, 16bit, 48kHz
AVCHD : Linear PCM 2ch, 16bit, 48kHz Dolby Digital 2ch, 16bit, 48kHz
Recording Frame Rate
XAVC QFHD (3840 x 2160) @29.97p, 25p, 23.98p 100Mbps/60Mbps
XAVC HD (1920 x 1080) @59.94p, 50p, 50 Mbps/35 Mbps
XAVC HD (1920 x 1080) @59.94i, 50i, 50 Mbps/35 Mbps/25 Mbps
XAVC HD (1920 x 1080) @29.97p, 25p, 23.98p, 50 Mbps/35 Mbps
XAVC HD (1280 x 720)@59.94p, 50p, 50Mbps
XAVC Proxy (1280 x 720) @59.94p, 50p, 29.97p, 25p, 23.98p 9Mbps
XAVC Proxy (640 x 360) @59.94p, 50p, 29.97p, 25p, 23.98p, 3Mbps
MPEG HD422 (1920 x 1080) @59.94i, 50i, 29.97p, 25p, 23.98p, 50 Mbps
MPEG HD422 (1280 x 720) @59.94p, 50p, 50Mbps
MPEG HD420 (1920 x 1080) @59.94i, 50i, 29.97p, 25p, 23.98p, HQ mode (35Mbps)
MPEG HD420 (1440 x 1080) @59.94i, 50i, HQ mode (35Mbps)
XAVC HD (1920 x 1080) @59.94p, 50p, 50 Mbps/35 Mbps
XAVC HD (1920 x 1080) @59.94i, 50i, 50 Mbps/35 Mbps/25 Mbps
XAVC HD (1920 x 1080) @29.97p, 25p, 23.98p, 50 Mbps/35 Mbps
XAVC HD (1280 x 720)@59.94p, 50p, 50Mbps
XAVC Proxy (1280 x 720) @59.94p, 50p, 29.97p, 25p, 23.98p 9Mbps
XAVC Proxy (640 x 360) @59.94p, 50p, 29.97p, 25p, 23.98p, 3Mbps
MPEG HD422 (1920 x 1080) @59.94i, 50i, 29.97p, 25p, 23.98p, 50 Mbps
MPEG HD422 (1280 x 720) @59.94p, 50p, 50Mbps
MPEG HD420 (1920 x 1080) @59.94i, 50i, 29.97p, 25p, 23.98p, HQ mode (35Mbps)
MPEG HD420 (1440 x 1080) @59.94i, 50i, HQ mode (35Mbps)
Recording Frame Rate (contd)
MPEG HD420 (1280 x 720) @59.94p, 50p, HQ mode (35Mbps)
MPEG HD Proxy (1280 x 720) @59.94p, 50p, 29.97p, 25p, 23.98p, 9Mbps
MPEG HD Proxy (640 x 360) @59.94p, 50p, 29.97p, 25p, 23.98p, 3Mbps
AVCHD (1920 x 1080)@59.94p, 50p, PS mode (28 Mbps)
AVCHD (1920 x 1080) @59.94i/50i/29.97p/25p/23.98p, FX mode (24 Mbps), FH mode(17 Mbps)
AVCHD (1280 x 720)@59.94p, 50p, FX mode (24 Mbps) FH mode (17 Mbps) HQ mode (9 Mbps)
MPEG HD Proxy (1280 x 720) @59.94p, 50p, 29.97p, 25p, 23.98p, 9Mbps
MPEG HD Proxy (640 x 360) @59.94p, 50p, 29.97p, 25p, 23.98p, 3Mbps
AVCHD (1920 x 1080)@59.94p, 50p, PS mode (28 Mbps)
AVCHD (1920 x 1080) @59.94i/50i/29.97p/25p/23.98p, FX mode (24 Mbps), FH mode(17 Mbps)
AVCHD (1280 x 720)@59.94p, 50p, FX mode (24 Mbps) FH mode (17 Mbps) HQ mode (9 Mbps)
Recording/Playback Time
XAVC-L QFHD 100 mode, Approx. 65 min with 64 GB memory card
XAVC-L QFHD 60 mode, Approx. 100 min with 64 GB memory card
XAVC-L HD 50 mode, Approx. 120 min with 64 GB memory card
XAVC-L HD 35 mode, Approx. 170 min with 64 GB memory card
XAVC-L HD 25 mode, Approx. 220 min with 64 GB memory cardMPEG HD422 @LPCM 2ch 50 Mbps, Approx. 110 min with 64 GB memory card
MPEG HD420 @LPCM 2ch HQ Mode, Approx. 170 min with 64 GB memory card
XAVC-L QFHD 60 mode, Approx. 100 min with 64 GB memory card
XAVC-L HD 50 mode, Approx. 120 min with 64 GB memory card
XAVC-L HD 35 mode, Approx. 170 min with 64 GB memory card
XAVC-L HD 25 mode, Approx. 220 min with 64 GB memory cardMPEG HD422 @LPCM 2ch 50 Mbps, Approx. 110 min with 64 GB memory card
MPEG HD420 @LPCM 2ch HQ Mode, Approx. 170 min with 64 GB memory card
Recording/Playback Time (Contd)
AVCHD@LPCM 2ch PS Mode, Approx. 290 min with 64 GB memory card
AVCHD@LPCM 2ch FX Mode, Approx. 340 min with 64 GB memory card
AVCHD@LPCM 2ch FH Mode, Approx. 450 min with 64 GB memory card
AVCHD@LPCM 2ch HQ Mode, Approx. 750 min with 64 GB memory card
AVCHD@LPCM 2ch FX Mode, Approx. 340 min with 64 GB memory card
AVCHD@LPCM 2ch FH Mode, Approx. 450 min with 64 GB memory card
AVCHD@LPCM 2ch HQ Mode, Approx. 750 min with 64 GB memory card
Lens Mount
Fixed
Zoom Ratio
12x (optical), servo
Focal Length
f = 9.3 – 111.6 mm equivalent to f = 29.0 – 348.0 mm on 35 mm lens (16:9)
Iris
F2.8 – F4.5 auto/manual selectable
Focus
AF/MF selectable, 10 mm to ∞ (Wide), 1000 mm to ∞ (Tele)
Image Stabilizer
ON/OFF selectable, shift lens
Filter Diameter
M62 mm
Imaging Device (Type)
1.0-type (13.2 mm x 8.8 mm) back-illuminated Exmor RS CMOS sensor
Imaging Device (Pixel Count)
Approx. 20 M pixels (total)
Approx. 14.2 M pixels (Effective)
Approx. 14.2 M pixels (Effective)
Effective Picture Elements
3840 (H) x 2160 (V)
Built-in Optical Filters
ND filters
OFF: CLEAR
1: 1/4ND
2: 1/16ND
3: 1/64ND
OFF: CLEAR
1: 1/4ND
2: 1/16ND
3: 1/64ND
Minimum Illumination
1.7 lux (Low Lux)
Shutter Speed
[60i]: 1/8 – 1/10,000 (1/6 – 1/10,000 when shooting with 24p)
[50i]: 1/6 -1/10,000
[50i]: 1/6 -1/10,000
Slow & Quick Motion Function
[60i]: XAVC HD: Frame rate selectable 1.2.4.8.15.30,60 fps
[50i]: XAVC HD: Frame rate selectable 1.2.3.6.12.25,50 fps
[60i]: MPEG HD: Frame rate selectable 1.2.4.8.15.30 fps
[50i]: MPEG HD: Frame rate selectable 1.2.3.6.12.25 fps
[60i]: AVCHD: Frame rate selectable 1.2.4.8.15.30,60 fps
[50i]: AVCHD: Frame rate selectable 1.2.3.6.12.25,50 fps
[50i]: XAVC HD: Frame rate selectable 1.2.3.6.12.25,50 fps
[60i]: MPEG HD: Frame rate selectable 1.2.4.8.15.30 fps
[50i]: MPEG HD: Frame rate selectable 1.2.3.6.12.25 fps
[60i]: AVCHD: Frame rate selectable 1.2.4.8.15.30,60 fps
[50i]: AVCHD: Frame rate selectable 1.2.3.6.12.25,50 fps
Super Slow Motion Function
[60i]: XAVC HD: Frame rate selectable 120 fps
[50i]: XAVC HD: Frame rate selectable 100 fps
[50i]: XAVC HD: Frame rate selectable 100 fps
White Balance
Preset (Indoor: 3200K, Outdoor: 5600K±7 steps, Color temperature set range: 2300-15000K), Onepush A, B, Auto selectable
Gain
-3, 0, 3, 6, 9, 12,15, 18, 21, 24, 27, 30, 33 dB, AGC
Gamma Curve
Selectable
Audio Input
XLR-type 3-pin (female) (x2), line/mic/mic +48 V selectable
Video Output
Integrated into Multi/Micro USB jack (x1), RCA pin(x1), Composite 1.0Vp-p, 75 Ω
Audio Output
Integrated into Multi/Micro USB jack(x1), RCA pin(Monaural)(x1)
SDI Output
BNC (x1), 3G/HD/SD SMPTE ST 424/ST 292-1/ST 259 standards
Headphone Output
Stereo mini jack (x1)
Speaker Output
Monaural
DC Input
DC jack
Remote
Stereo mini-mini jack (Φ2.5 mm)
HDMI Output
HDMI connector (Type A)
Viewfinder
1.0cm(0.39 type) OLED, Approx. 1.44M dots
LCD
8.8cm (3.5 type), Approx. 1.56M dots
Built-in Microphone
Omni-directional stereo electret condenser microphone
Type
MS/SD(1),SD(1)
Supported Format
IEEE 802.11 b/g/n
Frequency Band
2.4 GHz bandwidth
Security
WEP/WPA-PSK/WPA2-PSK
NFC
NFC Forum Type 3 Tag compliant
